| Screen Type |
Interactive Flat Panel Display |
| Brand |
Clinux Digital |
| Model No |
I6501 / I7501 / I8601 |
| Size |
65 Inch / 75 Inch / 86 Inch |
| Display Resolution |
3840 × 2160 (UHD) |
| Aspect Ratio |
16:9 |
| RAM |
8GB System Memory |
| ROM |
128GB System Storage |
| Android Version |
Android 16 |
| Contrast Ratio |
1200:1 / 4000:1 |
| Colors |
1.07 Billion Colors |
| Brightness |
450 cd/m² |
| Viewing Angle |
178° |
| Screen Surface |
4 mm Thickness Anti-Glare Glass |
| Display Output |
VBYONE (4K@60Hz) |
| HDMI Output |
HDMI Output (1080P@60Hz) |
| HDMI Input |
HDMI 2.1 Input (4K@60Hz) |
| Display Input |
1 × OPS, after connecting OPS sub-board, can be connected to standard OPS PC |
| Touch Technology |
IR Touch |
| Touch Points |
40 Points (Windows 7/8/10), 50 Points Touch (Android) |
| Touch Accuracy |
±2 mm (Windows) |
| Recognition |
Finger or Passive Stylus |
| Response Rate |
<10 ms (Max Touch Inputs) |
| Response Distance |
2 mm |
| Response Time |
<5 ms |
| Hotspot |
Yes |
| Bluetooth |
Version 5.0 |
| Audio |
Support 2 × SPK (2.2 Channel HD Audio), up to 4 × 8Ω 15W, Dual-Channel Speaker |
| Audio Port |
1 × LINE IN, 1 × LINE OUT, 1 × S/PDIF |
| Network |
10/100/1000 Mbps GMAC Ethernet |
| WiFi |
WiFi 6 + BT 5.4 |
| WiFi Standard |
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz / 5GHz) |
| Front Ports |
USB 3.0 × 2 (Public), Touch Out USB Type-A × 1, HDMI IN 2.0 × 1, Type-C × 1 |
| Indicator |
Red / Blue |
| Buttons |
Screen Record, Image, Aspect Ratio, V–, V+, Settings |
| Speaker |
20W × 2 |
| USB |
1 × USB 3.0, 7 × USB 2.0, 1 × Type-B OUT, (Excluding Front Panel and OPS Interface USB Ports) |
| UART |
1 × Touch-following, 1 × TTL Debug, 1 × RS232 |
| Chipset |
RK3576 |
| CPU |
Octa-Core 64-bit Processor (Quad-Core Cortex-A53 + Quad-Core Cortex-A72, up to 2.2GHz) |
| GPU |
Mali-G52 MC3 @ 1GHz |
| Graphics API |
OpenGL ES 1.1 / 2.0 / 3.2, OpenCL 2.0, Vulkan 1.1 |
| Graphics Engine |
Integrated High-Performance 2D Acceleration Hardware |
| Compatible With |
Windows, Mac, Linux, Chrome OS |
| Gross Weight |
I6501 – 56 kg, I7501 – 68 kg, I8601 – 98 kg |
| Input Voltage |
100–240V (50/60Hz 4A) |
| Power Consumption |
I6501 – Max 280W, I7501 – Max 350W, I8601 – Max 450W |
| Software Feature |
Device Management System (DMS) |
| Card Type |
NFC |
| NPU |
6 TOPS |
| Video CODEC |
Video Decoder: 8K@30fps (H.265 / H.264 / AVS3 / VVC / AV1 / HEVC), Video Encoder: 4K@30fps (H.265 / H.264) |
| Others |
8 × ADC Keys, 1 × IR + LED, 1 × Front Panel (Support Additional USB & HDMI Input) |
| Camera & Mic |
48MP Camera and 8 Array Mic (Optional) |
